  • PlusOne® Energy Efficiency: ENERGY STAR® certified, featuring 95% AFUE across all model sizes
  • PlusOne® Diagnostics: With the Rheem Contractor & EcoNet® Apps, built-in EcoNet® & Bluetooth®1 technology makes monitoring, troubleshooting and repairing the product easier than ever before
  • Dip Switch Free Installation Commissioning via Bluetooth® Technology: Seamless final install step without DIP switch configuration using the Rheem Contractor App
  • PlusOne® Ignition System: Proven Direct Spark Ignition (DSI) for reliability and longevity
  • PlusOne® Water Management System: Rheem-exclusive patented block drain sensor that automatically shuts off the furnace when the drain is blocked, and also alerts the contractor via diagnostic code
  • Constant CFM Motor: Truly variable speed technology allows for ultimate humidity control, quieter sound levels and year-round energy savings
  • Quieter Operation2: A fully insulated blower cabinet, solid bottom and truly variable speed airflow technology makes this furnace one of the quieter options available
  • EcoNet® Enabled Furnace: The latest in sensor technology and the EcoNet® monitoring system provides a new level of protection, control and energy savings
  • Allows on-the-go Control and receipt of system alerts by the homeowner via the EcoNet® Smart Thermostat and EcoNet® App3

Go to Specification Sheet

1The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Rheem® is under license. Other trademarks and trade names are those of their respective owners.
2Based on manufacturer’s furnace offering, and the product’s heating stages, motor type and cabinet insulation. Sound levels are also dependent on furnace location and installation.
3Wifi broadband internet connection required. Download the EcoNet® App from the App Store® or Google Play® to set up your EcoNet® Smart Thermostat. Receipt of notifications depend on home WiFi set up. Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its affiliates.

1 - 7 of 7 | Results Per Page | View | Unit of Measure
1

Item #

Input

Heating Capacity

Motor H.P.

Approx. Shipping Weight

N/A 42000 Btu/h12.30 kW N/A 39900 Btu/h11.69 kW N/A 1/2 hp373 W N/A 56 kg123 lb
N/A 56000 Btu/h16.41 kW N/A 53200 Btu/h15.59 kW N/A 1/2 hp373 W N/A 58 kg128 lb
N/A 70000 Btu/h20.51 kW N/A 66500 Btu/h19.49 kW N/A 1/2 hp373 W N/A 61 kg133.5 lb
N/A 70000 Btu/h20.51 kW N/A 66500 Btu/h19.49 kW N/A 1 hp746 W N/A 66 kg146.5 lb
N/A 84000 Btu/h24.61 kW N/A 79800 Btu/h23.39 kW N/A 1 hp746 W N/A 68 kg150 lb
N/A 98000 Btu/h28.72 kW N/A 93100 Btu/h27.28 kW N/A 1 hp746 W N/A 70 kg155 lb
N/A 112000 Btu/h32.82 kW N/A 106400 Btu/h31.18 kW N/A 1 hp746 W N/A 86.2 kg190 lb
