  • PlusOne® Ignition System: Direct Spark Ignition (DSI) for reliability and longevity.
  • PlusOne® Diagnostics1: The Rheem Contractor App and built-in EcoNet® & Bluetooth®2 technology, makes monitoring, troubleshooting and repairing the product easier than ever before
  • Two-Stage Scroll Compressors on all Models: Modulates between two capacity settings — 67% and 100% — providing more precise temperature control, lower humidity and greater efficiency in comparison to single stage compressors. It uses 70% fewer moving parts which also increases efficiency and reliability
  • MicroChannel Evaporator & Condenser Coil: Delivers superior performance with a robust surface, a decreased refrigerant requirement and is lighter than conventional copper tube/aluminum fin coils.All-aluminum construction offers superior protection against formicary corrosion and aluminum tube rubbing damage. Design allows for easier and faster cleaning.
  • Thermal Expansion Valves: Standard on all models for precise superheat control, reliability, and energy efficiency at all operating conditions.
  • High and Low Pressure Control: Standard on all models for refrigerant component protection and reliability
  • Easily Accessible Control Box, Furnace Compartment and Slide-Out Blower Section Allows for faster installability and serviceability.
  • Tested. Trusted. Tough. 100% Factory Run Tested.
  • PlusOne® Refrigerant Detection System Integrated, patented design providing system protection and homeowner peace-of-mind with low GWP refrigerant monitoring

1Bluetooth functionality applies to the heating section only.
2The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Rheem® is under license. Other trademarks and trade names are those of their respective owners.

1 - 14 of 14 | Results Per Page | View | Unit of Measure
1
Clear Filter

Nominal Cooling Capacity (Btu/h)

Nominal Cooling Capacity (kW)

Nominal CFM (ft³/min)

Nominal CFM (L/s)

AHRI Rated CFM (ft³/min)

AHRI Rated CFM (L/s)

Item #

Nominal Cooling Capacity

Nominal CFM

AHRI Rated CFM

Weight

N/A 24000 Btu/h7.03 kW N/A 800 ft³/min378 L/s N/A 840 ft³/min396 L/s N/A 227 kg500 lb
N/A 24000 Btu/h7.03 kW N/A 800 ft³/min378 L/s N/A 840 ft³/min396 L/s N/A 227 kg500 lb
N/A 36000 Btu/h10.55 kW N/A 1200 ft³/min566 L/s N/A 1230 ft³/min580 L/s N/A 227 kg500 lb
N/A 36000 Btu/h10.55 kW N/A 1200 ft³/min566 L/s N/A 1230 ft³/min580 L/s N/A 229 kg505 lb
N/A 36000 Btu/h10.55 kW N/A 1200 ft³/min566 L/s N/A 1230 ft³/min580 L/s N/A 227 kg500 lb
N/A 36000 Btu/h10.55 kW N/A 1200 ft³/min566 L/s N/A 1230 ft³/min580 L/s N/A 229 kg505 lb
N/A 48000 Btu/h14.07 kW N/A 1600 ft³/min755 L/s N/A 1430 ft³/min675 L/s N/A 229 kg505 lb
N/A 48000 Btu/h14.07 kW N/A 1600 ft³/min755 L/s N/A 1430 ft³/min675 L/s N/A 231 kg510 lb
N/A 48000 Btu/h14.07 kW N/A 1600 ft³/min755 L/s N/A 1430 ft³/min675 L/s N/A 229 kg505 lb
N/A 48000 Btu/h14.07 kW N/A 1600 ft³/min755 L/s N/A 1430 ft³/min675 L/s N/A 231 kg510 lb
N/A 60000 Btu/h17.58 kW N/A 2000 ft³/min944 L/s N/A 1820 ft³/min859 L/s N/A 231 kg510 lb
N/A 60000 Btu/h17.58 kW N/A 2000 ft³/min944 L/s N/A 1820 ft³/min859 L/s N/A 234 kg515 lb
N/A 60000 Btu/h17.58 kW N/A 2000 ft³/min944 L/s N/A 1820 ft³/min859 L/s N/A 231 kg510 lb
N/A 60000 Btu/h17.58 kW N/A 2000 ft³/min944 L/s N/A 1820 ft³/min859 L/s N/A 234 kg515 lb
